Equipment

MCT (Machining Center)

High-Speed Parts Processing Machining Center [VESTA-1000]

Equipment Overview

• High-Speed High-Performance Spindle : 10,000rpm
• Transfer Distance(X / Y / Z) – Processable Size : 1,000mm × 550mm × 500mm
• Motor Direct Coupling Type High Speed Spindle : Semipermanent Grease Lubrication
• Powerful Roller LM Guide System applied to All Axes

High-Productivity Machining Center [SIRIUS-7040]

Equipment Overview

• High-Performance Motor Direct Coupling Type Spindle
SIRIUS-7040[BT-40] : 10,000rpm(15kW / 11kW)
• Spindle Jacket Cooling and Grease Lubrication Type
• Powerful Roller LM Guide System applied to All Axes
• Transfer Distance (X / Y / Z) – Processable : 1,500mm × 700mm × 650mm

High-Speed High-Productivity Tapping Center [HIT-400]

Equipment Overview

• Transfer Distance (X / Y / Z) : 520 / 400 / 300
• Maximum Load : 200 kgf
• Maximum Tool Retention : 14ea
• Rapid Transfer Speed (X / Y / Z) : 60 / 60 / 60 m/min
• Table Size : 600 x 400

CNC ( Computerized Numerical Control)

Horizontal Turning Center for Heavy-Duty Cutting (Hi-TECH-400)

Equipment Overview

• High-Power Spindle Hi-TECH400 : 2,500rpm(2218.5kw / 18.5kw)
• High-rigidity and all-in-one 45° inclined bed
• Toolbar division time: 0.35 s / 1 side
• Rapid Transfer Speed(X / Z) : 20 m/min / 20 m/min
• Easy to add and maintain high-speed turn–mill and subspindle
• Processable Size : 12 Inch

High-productivity horizontal turning center (Hi-TECH 200/200A)

Equipment Overview

• High-Power Spindle : 5,000rpm(15kw / 11kw)
• High-rigidity all-in-one bed
• Toolbar division time : 0.15sec/1 side
• Rapid Transfer Speed(X / Z) : 30 m/min / 30 m/min
• Wide workspace / excellent workability
• Easy to add and maintain high-speed turn–mill and subspindle
• Processable Size : 10 Inch

Cleaning Equipment

Water-producing machine for cleaning processed parts(SHWET-D/I)

Equipment Overview

• Produce Pure Water and Ultrapure Water
• Accurate Resistivity Monitoring
• Automatic pressurization and transfer system for work and wet station
• Circulation function for maintaining purity
• Rejection rate: ions, particles, microorganisms, organic matters ≥ 99%

Ultrasonic cleaning by dipping the part to be washed in the tank(JW-1-2400W)

Equipment Overview

• Proper for cleaning precision parts
• Physical action of ultrasonic waves using organic solvent and chemical action of detergent enable perfect cleaning
• Ultrasonic waves thoroughly clean even the inside of small holes of the part to be washed in the tank, thereby improving the product quality.

Oven Equipment for drying washed product (JW-407)

Equipment Overview

• Drying and sterilization of processed products
• Tamp range Ambient to 200℃
• Temp accuracy ±1 ℃ at 100 ℃
• Rapid drying by forced circulation method and even temperature distribution inside the chamber

Division	Type	Maker	Model	Specification	Unit
Metal processing	MCT	Hwacheon	SIRIUS 7040	Unit 7	1
	MCT	Hwacheon	VESTA 1000	Unit 5	6
	CNC	Hwacheon	HI-TECH 400	12"	1
	CNC	Hwacheon	HI-TECH 200C	10"	7
	Universal Milling	Namcheon	MSM-T	300 x 1300	1
	Universal Lathe	Hwacheon	HL-460	580 x 1500	1
Resin processing	CNC	Hwacheon	HI-TECH 200A	10"	4
	MCT	Hwacheon	VESTA 1300B	Unit 7	1
	MCT	Hwacheon	VESTA 1000	Unit 5	9
	MCT	Hwacheon	HIT-400	600 x 400	6
	MCT	Hartford	LG-1000A	Unit 7	1
	MCT	Doosan Infracore	DNM-650	Unit 6	1
	MCT	Doosan Infracore	DNM500	Unit 5	2
Polishing	Ultrasonic Cleaner	Jungwoo Ultrasonic Industry	JW-1-2400W	For cleaning	1
	Oven	Jungwoo Ultrasonic Industry	JW-407	For cleaning	1
	DIW System	Sinhan Science Tech	SHWET-D/I	For cleaning	2
